VKK series vibratory dryer machines can be used for drying the surface of wet finished parts. These type of machines have heaters inside of the bowl for heating corn cobs. The corn cobs are used to achive spotless and polished surface of the parts.
Vibratory Dryer Machine
VKK Series
VKK series vibratory dryer machines can be used for drying the surface of wet finished parts. These type of machines have heaters inside of the bowl for heating corn cobs. The corn cobs are used to achive spotless and polished surface of the parts.
Pneumatic Sound Lid
Pneumatic Flap Control
Frequency Control
External Dust Collector
Control Panel Base
Lorem ipsum dolor sit amet, lorem ipsum dolor sit amet, lorem ipsum.
Polishing
Radiusing
Oil Cleaning
Rust Cleaning
Antic Oxide
Descaling
Cleaning
Polisaj
Aluminium
Iron-Steel
Copper
Brass
Zamak
Powder Metal
Gold-Silver
Lead
Titanium
ABS & Polyester
Rubber
Acrylic
Bacalite
Stainless Steel
Furniture accessory parts
Sheet metal press parts
Injection molding, centrifugal, sand, gravity die casting parts
All kinds of parts machining
Fitting and valve parts
Fork, spoon, knife
Jewelry parts
Automotive parts industry
Acrylic teeth and other dental parts
Aviation and aircraft industry
Medical and surgical instruments
Costume jewelry and accessory parts
Tumbled marble and natural stone
| Type | VKK100 | VKK200 | VKK400 | VKK600 | VKK900 | VKK1200 | VKK1600 | |
| Gross Volume | Lt | 112 | 213 | 405 | 647 | 903 | 1198 | 1585 |
| Usable Volume | Lt | 70 | 160 | 310 | 490 | 680 | 905 | 1190 |
| Heater Power | W | 1050 | 1800 | 3000 | 4500 | 6000 | 6000 | 7500 |
| Pu Thickness | mm | 3-5 | 3-5 | 3-5 | 3-5 | 3-5 | 3-5 | 3-5 |
| Engine Power | Kw | 1,1 | 1,1 | 1,9 | 2,5 | 5 | 7 | 11 |
| Voltage | V/Hz. | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
| Operating Speed | rpm | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Weight | Kg | 280 | 420 | 600 | 850 | 1200 | 1500 | 2000 |
| A | mm | 265 | 320 | 360 | 440 | 500 | 560 | 620 |
| B | mm | 385 | 435 | 570 | 640 | 680 | 720 | 820 |
| C | mm | 890 | 1100 | 1260 | 1500 | 1680 | 1840 | 2000 |
| D | mm | 1190 | 1420 | 1590 | 1835 | 2150 | 2350 | 2520 |
| E | mm | 970 | 1200 | 1400 | 1625 | 1820 | 2000 | 2200 |
| F | mm | 1500 | 1740 | 1850 | 2100 | 2300 | 2600 | 2900 |
| G | mm | 440 | 500 | 510 | 470 | 490 | 520 | 550 |
| H | mm | 900 | 980 | 1150 | 1150 | 1240 | 1330 | 1420 |
| J | mm | 1060 | 1120 | 1300 | 1300 | 1440 | 1540 | 1600 |
| K | mm | 2400 | 2630 | 2850 | 3000 | 3250 | 3650 | 3850 |
| L | mm | 130 | 150 | 150 | 175 | 200 | 230 | 260 |
| M | mm | 360 | 360 | 400 | 500 | 580 | 640 | 800 |
| N | mm | 250 | 250 | 275 | 275 | 350 | 420 | 420 |
